BCO CL2 BD HF
Space-saving, compact combined arrester with a width of 6 mm and push-in connection technology with status indication for protecting one pair of unearthed high-frequency bus systems as well as balanced interfaces.
1 Product
Part No. 927971 BCO CL2 BD HF 5
GTIN 4013364411999, Customs tariff No.: 85363010, Gross weight: 57.86 g, PU: 1.00 pc(s)
Images
:quality(98)/www.dehn-international.com/store/f/8316679/HDVORSCHAU/927971.jpg)
Additional information
Certificates
Technical data
| SPD class | L |
| Impulse category | D1, C1, C2, C3, B2 |
| Nominal voltage (UN ) | 5 V |
| Max. continuous operating voltage (d.c.) (UC ) | 8.5 V |
| Max. continuous operating voltage (a.c.) (UC ) | 6.0 V |
| Nominal current at 70 °C (IL ) | 0.75 A |
| D1 Total lightning impulse current (10/350 µs) (Iimp ) | 3 kA |
| D1 Lightning impulse current (10/350 µs) per line (Iimp ) | 1.5 kA |
| C2 Total nominal discharge current (8/20 µs) (In ) | 10 kA |
| C2 Nominal discharge current (8/20 µs) per line (In ) | 5 kA |
| Voltage protection line-line for In C2 (Up ) | ≤ 42 V |
| Voltage protection level line-PG for In C2 (Up ) | ≤ 600 V |
| Voltage protection level line-line for In C1 (Up ) | ≤ 42 V |
| Voltage protection level line-PG for In C1 (Up ) | ≤ 600 V |
| Voltage protection level line-line for 1 kV/µs C3 (Up ) | ≤ 15 V |
| Voltage protection level line-PG for 1 kV/µs (UP ) | ≤ 600 V |
| Series resistance per line | 1 ohms |
| Cut-off frequency line-line (fG ) | 100 MHz |
| Operating temperature range (TU ) | -40 °C ... +80 °C |
| Operating state / fault indication | green / red |
| Degree of protection | IP 20 |
| For mounting on | 35 mm DIN rails acc. to EN 60715 |
| Connection (input / output) | push-in / push-in |
| Cross-sectional area, solid | 0.2-2.5 mm2 |
| Cross-sectional area, flexible | 0.2-2.5 mm2 |
| Earthing via | 35 mm DIN rails acc. to EN 60715 |
| Enclosure material | polyamide PA 6.6 |
| Colour | yellow |
| Test standards | IEC 61643-21 / EN 61643-21 |
| Approvals | UL, ATEX, IECEx, SIL |
| ATEX approvals | TÜV 20 ATEX 8527 X: II 3G Ex ec IIC T4 Gc |
| IECEx approvals | IECEx TUR 20.0063X: Ex ec IIC T4 Gc |
| Extended technical data: | - - - - - - - - - - - - - - - - - - - - |
| – Max. discharge current (8/20 µs) [1/2 - PG], [1+2 - PG] (Imax ) | 20 kA |
| – Discharge current (8/20 µs) [1/2 - PG], [1+2 - PG] | 10 kA (10x) |
| – Voltage protection level line-PG at 1 kV/μs C3 after being subjected to Imax (Up ) | ≤ 600 V |
